Intel® Centrino® 2 Processor Technology
Genuine Windows Vista® Business (64-bit)
High Durability & Light Weight: Premium Carbon Body
Real Wide 13.1-inch Clear Tough LCD [Rich Colour]
Blu-ray Disc™ Drive
Bluetooth standard Ver. 2.1+EDR
Windows 7 Individual Drivers and Utilities
Please install the following:
1. Graphics Driver 2. Audio Driver 3. Audio HDMI Driver 4. Wireless LAN Driver 5. Ethernet Driver 6. Bluetooth Driver
Note: After executing the installer, please manually install the setup.exe in C:\Upgrade\Drivers\Broadcom
7. TPM Infineon 8. SD Card Driver 9 Memory Stick Driver 10. CF Card Driver (only applicable to models with CF Card slot) 11. Fingerprint Driver (only applicable to models with Fingerprint Sensor) 12. Pointing Driver 13. Protect Suite QL (only applicable to models with Fingerprint Sensor) 14. Sony Programmable Input/Output Controller (SPIC) Driver 15. Sony Firmware Extension Parser (SFEP Driver) 16. Sony Shared Library 17. Setting Utility Series 18. VAIO Event Service 19. VAIO Control Center 20. Battery Checker 21. VAIO Launcher 22. VAIO Mode Switch (for VGN-SR models only) 23. VAIO Power Management 24. VAIO Location Utility 25. VAIO Update 26. VAIO Smart Network
- Specifications
Architecture | ||
Processor Technology | : | Intel® Centrino® 2 Processor Technology |
Processor Name | : | Intel® Core™2 Duo Processor P9600 (2.66 GHz) |
Network Connection | : | Intel® WiFi Link 5100 |
Chipset | : | Mobile Intel® GM45 Express Chipset |
Processor System Bus | : | 1066 MHz |
Memory Bus | : | 1066 MHz |
Cache Memory | : | 6 MB |
Main Memory | ||
Pre-installed/Max | : | 4 GB DDR3 SDRAM*3 (Max) |
SO-DIMM Slots | : | 2 SO-DIMM slots (The pre-installed memory module uses two) |
Hard Disk Drive | ||
Hard Disk Drive | : | 320 GB*4 (Serial ATA, 7200 rpm) |
Optical Disc Drive | ||
Drive | : | Blu-ray Disc™ Drive |
Maximum Reading Speed | : | BD-ROM: 2x/BD-R: 2x (SL), 2x (DL)/BD-RE: 2x (SL), 2x (DL)/DVD+R: 8x (SL), 6x (DL)/DVD-R: 8x (SL), 6x (DL)/DVD+RW: 6x/DVD-RW: 6x/DVD-ROM: 8x/DVD-RAM: 5x/CD-ROM: 24x/CD-R: 24x/CD-RW: 24x |
Maximum Writing Speed | : | BD-R: 2x(SL), 1x (DL) /BD-RE: 2x(SL), 1x (DL) /DVD+R: 8x (SL)/DVD-R: 8x (SL)/DVD+RW: 4x/DVD-RW: 4x/DVD-RAM: 5x/CD-R: 16x/CD-RW: 10x |
Graphics | ||
Graphics Accelerator | : | NVIDIA® GeForce® 9300M GS notebook graphics processing unit (GPU) (SPEED MODE) / Mobile Intel® Graphics Media Accelerator 4500MHD (STAMINA MODE) |
Dedicated Video Memory | : | 256 MB (SPEED MODE) |
Display | ||
Type | : | 13.1" wide (WXGA++: 1600 x 900) TFT colour display (Clear Tough LCD [Rich Colour]) |
Interface | ||
USB | : | High Speed USB 2.0 x 2 |
i.LINK(IEEE 1394) | : | 4 pin (S400) x 1 |
Network (RJ-45)Connector | : | 10Base-T/100Base-TX / 1000Base-T x 1 |
Display Output Connector | : | Analogue RGB, mini D-sub 15 pin x 1 |
Headphone | : | Stereo mini jack x 1 |
Microphone | : | Stereo mini jack x 1 |
HDMI In/Out Connector | : | Output x 1 |
Modem | : | V.92 and V.90 Compliant x 1 |
Memory Stick Slot | Memory Stick (Standard/Duo Size compatible, MagicGate compatible, Memory Stick PRO compatible, High-speed data transfer compatible)*5 | |
SD Memory Card Slot | : | SD Memory Card*6 (SDHC compatible, MMC compatible) |
PC Card Slot | : | ExpressCard™/34 x 1 |
DC IN | : | x 1 |
Others | : | Docking Station Connector x 1 |
Wireless Connection | ||
Wireless LAN Type | : | Integrated Wireless LAN IEEE 802.11a/b/g/Draft n |
Wireless LAN Data Rate | : | maximum 11Mbps (802.11b)/54 Mbps (802.11a/g) 300 Mbps (Draft 802.11n)*8 |
Wireless LAN Frequency | : | 5 GHz (802.11a/Draft n), 2.4 GHz (802.11b/g/Draft n) |
Bluetooth | : | Bluetooth standard Ver. 2.1+EDR |
Security/Utilities | ||
Fingerprint Sensor | : | x 1 |
Security Chip | : | TCG Ver.1.2 compliant Trusted Platform Module (TPM) |
Camera | ||
Front Side Camera | : | Effective pixels: 640x 480 |
Audio | ||
Sound Chip | : | Intel® High Definition Audio compatible , 3D audio (Direct Sound 3D support) |
Speaker | : | Built-in stereo speakers |
Microphone | : | Built-in monaural microphone |
Keyboard/Input Device | ||
Keyboard | : | Approx. 19 mm key pitch/2.5 mm keystroke , 82 keys |
Touchpad | : | Intelligent Touchpad |
Battery Life*9 | ||
Bundled Battery | : | VGP-BPS12 Lithium-ion battery: up to 5 hours of use |
Optional Long Battery | : | VGP-BPL12 Lithium-ion battery: up to 7.5 hours of use |
Size | ||
Dimensions (WxHxD) | : | 314 x 24.5-33.0 x 210 mm |
Weight | : | 1.53 kg (including the supplied battery) |
Included Software | ||
Video Edit/Playback | : | VAIO Movie Story, Adobe® Premiere® Elements® 7, VAIO Edit Components, WinDVD BD for VAIO |
BD/DVD Creation | : | Click to Disc*10, Click to Disc Editor*10 |
Music | : | VAIO MusicBox, SonicStage Mastering Studio |
Still Image/Photo | : | PMB (Picture Motion Browser), Windows® Photo Gallery, Adobe® Photoshop® Elements® 7 |
Home Network | : | VAIO Media plus |
Word Processor / Spreadsheet | : | 60-Day Trial Version of Microsoft® Office Professional 2007 |
Tool | : | Roxio Easy Media Creator, Adobe® Reader® 9, McAfee PC SecurityCenter 90-day Free Trial*12 |
Utilities | : | VAIO Control Center, VAIO Presentation Support, Infineon TPM Professional Package (Installer), Protector Suite QL, WebCam Companion, Magic-i™ Visual Effects |
Support | : | VAIO Recovery Center, VAIO Update, VAIO Data Restore Tool |
Supplied Accessories | ||
AC Adaptor | : | AC Adaptor (VGP-AC19V26) |
Battery | : | Lithium-ion battery (VGP-BPS12) |
Others | : | Cleaning cloth, Windows®XP Professional Install Disc |
